This page lists the technical specifications for Smoke Shield and form part of the larger SmokeShield user guide.



Name: SmokeShield

Model number: ZWA050

Dimensions: 115x115x47mm

Weight: 202g

Product ID: 0x0032

Product Type:

EU = 0x0002

Z-Wave Plus Certified: Yes

Z-Wave Chipset: EFR32ZG23

Z-Wave SDK Version: 7.22.0

Series 800: Yes

S2 Security: Yes

SmartStart: Yes

FLiRs supported: Yes

Long Range: Yes

LED Color: Green

LED activity: not configurable

Power supply:

battery power (1×ER14250 battery, 3.7V).

Not compatible to rechargeable

Sleep Current: 2uA

Shutoff Mode: 1uA

Active Mode: 26 uA/MHz

Inclusion/Exclusion Current: 8 mA

Voltage input:

Battery Power

Min Voltage = 2.6VDC
Max voltage = 3.9VDC

Repeater: No

Operating temperature:

0°C to 70°C

32°F to 158°F.

Waterproofing: IP20 rating

Operating distance:

    Mesh Network

        Up to 40m indoors.

        Up to 150m outdoors.

Certifications:


Specifications subject to change without notice due to continuing product improvement.
